Vacuum front top 2RT mold opening series

Machine Features

◆Special new-type track mold, with a lifting angle of up to 90 degrees, facilitating easy operation. When changing molds, it can be easily done without removing the track mold base.

◆ Equipped with dual power, dual oil pumps, dual motors, and dual coolers, the two axes operate independently.

◆ The oil system is specially designed to ensure vibration-free operation and excellent stability, with faster mold entry and exit, as well as faster ascent and descent compared to machines in the same industry.

◆ High vacuum levels are achieved through the use of average pumping methods, which stabilize the product and improve quality and production capacity.

◆ The vacuum gas storage tank is of a base-type design, providing ample storage space.

◆ Special mold-lifting mechanism design, ensuring long durability, silent, fast, and smooth mold insertion and removal.

◆ Suitable for precision products such as O-rings, press-fit components, and keyboards.
